Technical Specification

• Web Width : 310 mm
• Printing width : 300 mm
• Designed Mechanical Speed : 150 m/min
• Max. Unwind Diameter : 1000 mm
• Max. Rewind Diameter : 700 mm
• Max. West Winder Diameter : 500 mm
• All station UV Drying System (power - 22Kw min)
• All station IR Drying System (power-18Kw min)
• Cold Foil attachment
• Reverse printing attachment
• One die cutting station
• One sheet cutting station with conveyor
• Pneumatic lifting on unwinding roll
• Unwind & Winding station with auto tension controller
• 10 HP AC Variable Speed Drive
• Machine dimension : 6700 x 960 x 1900 mm (LxWxH)
• Approx. machine weight : 5000 kg
