Technical Specification

• Web width : 310 mm
• Stamping unit area size : 300 x 300 mm
• Die Cutting Unit area size : 300 x 300 mm
• Accuracy : +/-0.1mm
• Waste Rewinding Unit with separate motor
• Online Rewinding
• Auto unloading unit
• Main motor : 3 HP, DC. variable speed
• Plane Die Cutting Machines Speed is 7000 stroke/Hr. Maximum (Depend on Length)
• Paper Puling with Electronics Servo motor control system with Repeat Pass Scanner system
• With Sheet Cutting Unit
• Machine size : 3200 x 1200 x 1540 mm (LxWxH)
• Approx weight : 2500 kg
